- Features:Lacquered with imported PVDF materials assure the easy-clean and durable dirt resistance qualities,panama base fabrics give high tensile and tear strengths.Good flame retardant,anti-UV,anti-mildew,high abrasion resistance.
Products
Architectural Membranes
E5105gray（Special membrane materials for environmental protection engineering）
Architectural Membranes
E5105gray（Special membrane materials for environmental protection engineering）
E5105gray（Special membrane materials for environmental protection engineering）
More Information
|
Technical |
Technical data |
detection basis |
|
Base Fabric |
100% polyester |
DIN EN 60001 |
|
Total Weight(gsm/㎡) |
1050gsm/㎡ |
DIN EN ISO 2286-2 |
|
Total Thickness(mm) |
0.82mm |
|
|
Tensile Strength(Warp/Weft)(N/5cm) |
5300/5000N/5cm |
DIN 53354 |
|
Tear Strength(Warp/Weft)(N) |
800/700N |
DIN 53363 |
|
Adhesion(N/5cm) |
>130N/5cm |
DIN 53357 |
|
Threshold Temperature |
-30℃/+70℃ |
DIN EN 1876-2 |
|
Surface Treatment |
PVDF/Acrylic |
|
|
Flame Retardancy(can be customized) |
B1 |
DIN4102 |
